System |
|
Processor |
Quad Core Intel® Xeon®/Core™ i7 Processor (Kaby Lake-S/Skylake-S)
|
|
Chipset |
Intel® C236 |
|
BIOS |
AMI |
|
SIO |
IT8786E |
|
Memory |
2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC) |
|
I/O Interface |
|
Serial |
4 COM RS-232/422/485 (ESD 8KV) |
|
USB |
- 8 USB 3.0 (External)
- 1 USB 2.0 (Internal) |
|
Isolated DIO |
16 GPIO
|
|
LED |
Power, HDD, Wireless |
|
SIM Card |
3 SIM Card Socket (External) |
|
Expansion |
|
Mini PCIe |
3 Full-size for PCIe/USB/External SIM Card/mSATA
|
|
M.2 |
1 M.2 Socket (Key ID : M) |
|
Graphics |
|
Graphics Processor |
- Intel® HD Graphics 630/530
- NVIDIA GeForce® GTX 950
|
|
Interface |
8 Display interfaces :
- 1 DVI-D : Up to 1920 x1200 @ 60Hz
- 2 DVI-I : Up to 1920 x 1200 @ 60Hz
- 1 DisplayPort : Up to 4096 x 2304 @ 60Hz
- 3 DisplayPort : Up to 5120 x 3200 @ 60Hz
- 1 HDMI : Up to 5120 x 3200 @ 60Hz
|
|
Storage |
|
SATA |
2 SATA III support S/W RAID 0, 1 |
|
mSATA |
3 SATA III (Mini PCIe Type, 6Gbps)
|
|
M2DOM |
1 PCIe 3.0 (8GT/s) |
|
Storage Device |
- 1 CFast Socket, Push-in/Push-out Ejector
- 2 Front-access 2.5" SSD/HDD Tray
|
|
Audio |
|
Audio Codec |
Realtek ALC888S, 7.1 Channel HD Audio |
|
Audio Interface |
1 Mic-in, 1 Line-out |
|
Ethernet |
|
LAN 1 |
Intel® I219 GigE LAN supports iAMT 11.0 |
|
LAN 2 |
Intel® I210 GigE LAN |
|
Power |
|
Power Input |
10V to 36V, DC-in |
|
Power Interface |
3-pin Terminal Block : V+, V-, Frame Ground |
|
Ignition Control |
16 Mode (Internal) |
|
Remote Switch |
3-pin Terminal Block |
|
Surge Protection |
Up to 80V/1ms Transient Power |
|
Others |
|
TPM |
Optional Infineon SLB9665 supports TPM 2.0, LPC Interface |
|
Watchdog Timer |
Reset : 1 to 255 sec./min. per step |
|
Smart Management |
Wake on LAN, PXE supported |
|
HW Monitor |
Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
|
Software Support |
|
OS |
Windows 10, Windows 8.1, Windows 7, Linux |
|
Mechanical |
|
Dimension (W x L x H) |
260mm x 215mm x 79mm (10.2” x 8.5” x 3.1”) |
|
Weight |
4.5 kg (9.92 lb) |
|
Mounting |
- Wallmount by mounting bracket
- DIN Rail Mount (Optional)
- 2U Rackmount (Optional)
|
|
Environment |
|
Operating Temperature |
35W TDP CPU :
- Core™ i7 : -40°C to 60°C (-40°F to 140°F)
- Xeon® E3-1268L v5 : -40°C to 60°C (-40°F to 140°F)
65W TDP CPU :
Core™ i7 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 : -40°C to 45°C (-40°F to 113°F)
|
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Humidity |
5% to 95% Humidity, non-condensing |
|
Relative Humidity |
95% at 60°C |
|
Shock |
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
|
|
Vibration |
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
|
|
EMC |
CE, FCC, EN50155, EN50121-3-2 |
