SPC-5600

產品特色

    • 8核心第9代/第8代Intel®Core™ i7/i5/i3處理器 (Coffee Lake)，搭載Intel®H310晶片組
    • 雙通道DDR4 2666MHz高速記憶體，最高支援至64GB
    • 無風扇，-25°C至60°C工作溫度，可選配風扇設計
    • 支援2個DisplayPort和1個DVI顯示，2個獨立顯示，最高支援至4K解析度
    • 4個USB 3.1, 4 COM RS-232/422/485
    • 4個獨立乙太網路介面，採用ＩIntel®GigELAN，支援iAMT 12.0
    • 支援WiFi/4G/3G/LTE/GPRS/UMTS
    • 2個Mini PCIe插槽，支援PCIe/USB/SIM Card/mSATA擴充
    • 12V電源輸入
    • 支援TPM 2.0







    產品亮點

       Outstanding Performance

    • 8th gen Intel Core i7/i5/i3 processor (Coffee Lake) + Intel H310 chipset
    • 6 cores computing
    • 2 SO-DIMM sockets, up to 64GB DDR4 memory
    • High-speed data transfer : PCIe 3.0 (8GT/s), SATA III (6G), USB 3.1 (5G), GigE LAN (1G)
    • More than 10% system performance enhanced than Intel Kaby Lake platform






       Compact Integration

    • Dual independent displays : 2 DisplayPort, 1 DVI, up to 4K Resolution
    • 4 USB 3.1 ports, COM RS-232/422/485
    • 4 GigE LAN, iAMT 12.0 supported
    • SIM socket for WiFi/4G/3G/LTE/GPRS/UMTS









       User Friendly

    • Flexible CPU/Memory configuration
    • Smart System Management : TPM, Wake on LAN, PXE
    • 12V DC Power Input
    • Remote Power Switch
    • Optional fan operation







       Trusted Reliability

    • Fanless design
    • -25°C to 60°C Operation
    • Supports iAMT 12.0, TPM 2.0, RAID 0, 1
    • ECC Memory, Intel LAN
    • Industrial-grade longevity
    • Anti-shock, Anti-vibration
    • EN50155 & EN50121-3-2 compliant



產品簡介

    8核心第9代/第8代Intel®Core™ i7/ i5/i3處理器（Coffee Lake Refresh/Coffee Lake），採用Intel®H310晶片組，無風扇，-20°C至60°C工作溫度，可選配風扇，2個獨立顯示，最高4K解析度，4個USB 3.1，傑出的系統性能，支援WiFi/4G/3G/LTE/GPRS/UMTS，用戶友好的智慧管理，支援iAMT 12.0、TPM 2.0、12V直流電源輸入，亦可選擇9V~36V寬電壓，靈活擴充PCIe/USB/SIM Card/ mSATA介面，支援VESA mount和DIN-Rail裝置，Vecow SPC-5600系列無風扇嵌入式系統是您規劃新世代車輛運算、智慧製造、車載娛樂系統、智慧控制或任何工業4.0與工業物聯網IIoT相關的嵌入式方案時的智慧選擇。，






產品規格

System
Processor 8 Cores Intel® Core™ i7/i5/i3 processor (CFL-R S)
Chipset Intel® H310 Chipset
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC)
I/O Interface
Serial  4 COM RS-232/422/485 (ESD 8KV)
USB
- 4 USB 3.1 (External)
- 2 USB 2.0 (Internal)
LED Power, HDD
SIM Card  1 SIM Card Socket (Internal)
Expansion
Mini PCIe
2 Mini PCIe sockets：
- 1 Full-size for PCIe/USB/SIM Card
- 1 Full-size for PCIe/USB/mSATA
Graphics
Graphics Processor - Intel® UHD graphics 630
Interface
- 2 DisplayPort : Up to 4096 x 2304 @60Hz
- DVI-D : Up to 1920 x 1200 @60Hz
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe type, 6Gbps)
Audio
Audio Codec Realtek ALC888S, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
LAN 3 Intel® I210 GigE LAN
LAN 4 Intel® I210 GigE LAN
Power
Power Input 12V DC-in  (±5%)
Power Interface 3-pin Terminal Block：V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block
Others
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 209.0mm x 150.5mm x 75.0mm (8.23" x 5.93" x 2.95")
Weight 2.4 kg (5.29 lbs)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU：-25°C to 60°C (-13°F to 140°F)
65W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 60°C
Shock
- IEC 60068-2-27
- SSD : 50G@Wallmount, Half-sine, 11ms
Vibration
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
