System |
|
Processor |
Quad Core Intel® Core™ i7/i5/i3 U-series Processor (Whiskey Lake) |
|
Chipset |
Intel® SoC (Cannon Lake) |
|
BIOS |
AMI |
|
SIO |
IT8786E |
|
Memory |
1 DDR4 2400MHz SO-DIMM, up to 32GB |
|
Graphics |
|
Graphics Processor |
Intel® HD Graphics 620 |
|
Graphics Interface |
Dual display：
- DVI-D : Up to 1920 x 1200 @60Hz
- DisplayPort : Up to 4096 x 2304 @60Hz
|
|
Ethernet |
|
LAN 1 |
Intel® I219LM GigE LAN supports iAMT 12.0 |
|
LAN 2 |
Intel® I210 GigE LAN |
|
Audio |
|
Audio Codec |
Realtek ALC888S, 7.1 Channel HD Audio |
|
Audio Interface |
1 Mic-in, 1 Line-out |
|
Storage |
|
SATA |
1 SATA III (6Gbps) |
|
mSATA |
1 SATA III (Mini PCIe Type, 6Gbps) |
|
I/O Interface |
|
Serial |
2 COM RS-232/422/485 (ESD 8KV) |
|
USB |
4 USB 3.1 Gen 2 |
|
LED |
Power, HDD |
|
SIM |
1 SIM Card Socket (Internal) |
|
Expansion |
|
Mini PCIe |
2 Mini PCIe Socket：
- 1 Full-Size for PCIe/USB/Internal SIM Card
- 1 Full-Size for PCIe/USB/Optional mSATA
|
|
SUMIT A, B |
2 SUMIT Slot (Optional) |
|
Power |
|
Power Input |
9V to 48V, DC-in |
|
Power Interface |
3-pin Terminal Block：V+,V-, Frame Ground |
|
Ignition Control |
16 Model (Internal) |
|
Remote Switch |
3-pin Terminal Block：On, Off, IGN |
|
Others |
|
TPM |
Optional Infineon SLB9665 supports TPM 2.0, LPC Interface |
|
Watchdog Timer |
Reset : 1 to 255 sec./min. per step |
|
Smart Management |
Wake on LAN, PXE supported |
|
HW Monitor |
Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
|
Software Support |
|
OS |
Windows 10, Linux |
|
Mechanical |
|
Dimension |
150.4mm x 106.2mm x 62.1mm (5.92" x 4.18" x 2.44") |
|
Weight |
1.3 kg (2.87lb) |
|
Environment |
|
Operating Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Humidity |
5% to 95% Humidity, non-condensing |
|
Relative Humidity |
95% at 85°C |
|
Shock |
-IEC 60068-2-27
-SSD：50G @ wallmount, Half-sine, 11ms
|
|
Vibration |
-IEC 60068-2-64
-SSD：5Grms, 5Hz to 500Hz, 3 Axis
|
|
EMC |
CE, FCC, EN50155, EN50121-3-2 |
