产品应用

SPC-5600A

产品特色

    • 八核心第九代/第八代英特尔® 酷睿™ i7/i5/i3处理器 (Coffee Lake)，搭载英特尔® H310芯片组
    • 采用DDR4 2666MHz內存，可支持64GB
    • 无风扇设计，支持-25°C至60°C工作温度
    • 多重DisplayPort与DVI显示接口，可支持2个独立显示，最高支持4K分辨率
    • 4个USB 3.1接口，4个RS-232/422/485串口
    • 4个独立千兆网口，支持iAMT 12.0
    • 可支持WiFi/4G/3G/LTE/GPRS/UMTS
    • 2个Mini PCIe卡插槽，可支持PCIe/USB/SIM卡/mSATA扩充
    • 支持9V~36V直流输入
    • 支持TPM 2.0





    产品亮点

    Outstanding Performance
    • 8th gen Intel Core i7/i5/i3 processor (Coffee Lake) + Intel H310 chipset
    • 6 cores computing
    • 2 SO-DIMM sockets, up to 64GB DDR4 memory
    • High-speed data transfer : PCIe 3.0 (8GT/s), SATA III (6G), USB 3.1 (5G), GigE LAN (1G)
    • More than 10% system performance enhanced than Intel Kaby Lake platform






       Compact Integration
    • Dual independent displays : 2 DisplayPort, 1 DVI, up to 4K Resolution
    • 4 USB 3.1 ports, COM RS-232/422/485
    • 4 GigE LAN, iAMT 12.0 supported
    • SIM socket for WiFi/4G/3G/LTE/GPRS/UMTS



       User Friendly
    • Flexible CPU/Memory configuration
    • Smart System Management : TPM, Wake on LAN, PXE
    • 12V DC Power Input
    • Remote Power Switch
    • Optional fan operation



       Trusted Reliability
    • Fanless design
    • -25°C to 60°C Operation
    • Supports iAMT 12.0, TPM 2.0, RAID 0, 1
    • ECC Memory, Intel LAN
    • Industrial-grade longevity
    • Anti-shock, Anti-vibration
    • EN50155 & EN50121-3-2 compliant



产品简介

    搭载八核心第九代/第八代英特尔®酷睿™ i7/i5/i3处理器（Coffee Lake Refresh/Coffee Lake），搭载英特尔® H310芯片组，无风扇，支持-20°C至60°C工作温度，多重DisplayPort与DVI显示接口，最高支持4K分辨率， 4个USB 3.1接口，出色的系统性能，支持WiFi/4G/3G/LTE/GPRS/UMTS，用户友好的智能可管理性：支持iAMT 12.0、TPM 2.0，支持12V直流输入亦可选备9V至36V宽电压，PCIe/USB/SIM卡/mSATA扩充，Vecow SPC-5600系列精巧型无风扇嵌入式系统是您建构机器视觉、车载应用、智能制造、PIS乘客信息系统、智能监控或任何工业4.0/IIoT等解決方案不可或缺的利器。










产品规格

System
Processor 8 Cores Intel® Core™ i7/i5/i3 processor (CFL-R S)
Chipset Intel® H310 Chipset
BIOS AMI
SIO IT8786E
Memory 2 DDR4 2666MHz SO-DIMM, up to 64GB (ECC/Non-ECC)
I/O Interface
Serial  4 COM RS-232/422/485 (ESD 8KV)
USB
- 4 USB 3.1 (External)
- 2 USB 2.0 (Internal)
LED Power, HDD
SIM Card  1 SIM Card Socket (Internal)
Expansion
Mini PCIe
2 Mini PCIe sockets：
- 1 Full-size for PCIe/USB/SIM Card
- 1 Full-size for PCIe/USB/mSATA
Graphics
Graphics Processor - Intel® UHD graphics 630
Interface
- 2 DisplayPort : Up to 4096 x 2304 @60Hz
- DVI-D : Up to 1920 x 1200 @60Hz
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe type, 6Gbps)
Audio
Audio Codec Realtek ALC888S, 7.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN 2 Intel® I210 GigE LAN
LAN 3 Intel® I210 GigE LAN
LAN 4 Intel® I210 GigE LAN
Power
Power Input 9V to 36V DC-in
Power Interface 3-pin Terminal Block：V+, V-, Frame Ground
Remote Switch 2-pin Terminal Block
Others
TPM Optional Infineon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L x H) 209.0mm x 150.5mm x 75.0mm (8.23" x 5.93" x 2.95")
Weight 2.7 kg (5.95 lbs)
Mounting Wallmount by mounting bracket
Environment
Operating Temperature
35W TDP CPU：-25°C to 60°C (-13°F to 140°F)
65W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 60°C
Shock
- IEC 60068-2-27
- SSD : 50G@Wallmount, Half-sine, 11ms
Vibration
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2





资源

产品 档案内容 档案类型 发布日期 下载
SPC-5600A SPC-5600 DM (English) .PDF 2023/4/18 Download
SPC-5600A SPC-5600 DM (簡體中文) .PDF 2023/4/21 Download
SPC-5600A SPC-5600カタログ (日本語) .PDF 2023/4/21 Download
SPC-5600A SPC-5600 User Manual .PDF 2023/4/18 Download
SPC-5600A SPC-5600 Series CE and EN50155 & EN50121-3-2 Certification .PDF 2020/1/3 Download
SPC-5600A SPC-5600 Series CE Report .PDF 2020/1/3 Download
SPC-5600A SPC-5600 Series FCC Certification .PDF 2020/1/3 Download
SPC-5600A SPC-5600 Series FCC Report .PDF 2020/1/3 Download
SPC-5600A SPC-5600 Series EN50155 & EN50121-3-2 Report .PDF 2020/1/3 Download
SPC-5600A SPC-5600 Series High and Low Temperature Test Report .PDF 2020/6/1 Download
SPC-5600A SPC-5600 Series Vibration and Shock Test Report .PDF 2020/6/1 Download
SPC-5600A SPC-5600 Series (with Fan Bracket) High and Low Temperature Test Report .PDF 2020/6/1 Download
SPC-5600A SPC-5600 Series (with Fan Bracket) Vibration and Shock Test Report .PDF 2020/6/1 Download
SPC-5600A SPC-5600 Series Chipset Driver .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series Graphics Driver 01 .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series Graphics Driver 02 .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series LAN Driver .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series ME Driver 01 .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series ME Driver 02 .ZIP 2019/12/11 Download
SPC-5600A SPC-5600 Series Hardware Monitor UI UM .PDF 2019/12/13 Download
SPC-5600A SPC-5600 Series Hardware Monitor UI Beta .ZIP 2019/12/16 Download

索取报价

产品型号 详细内容 需求数量
SPC 5600A SPC-5600A, 9V to 36V DC-in, 4 GigE LAN, 4 USB 3.1, 4 COM, 1 SIM
i7-9700E 9th Gen Intel® Core™ i7-9700E Processor (12M Cache, up to 4.40 GHz)
i7-9700TE 9th Gen Intel® Core™ i7-9700TE Processor (12M Cache, up to 3.80 GHz)
i5-9500E 9th Gen Intel® Core™ i5-9500E Processor (9M Cache, up to 4.20 GHz)
i5-9500TE 9th Gen Intel® Core™ i5-9500TE Processor (9M Cache, up to 3.60 GHz)
i3-9100E 9th Gen Intel® Core™ i3-9100E Processor (6M Cache, up to 3.70 GHz)
i3-9100TE 9th Gen Intel® Core™ i3-9100TE Processor (6M Cache, up to 3.20 GHz)
i7-8700 8th Gen Intel® Core™ i7-8700 Processor (12M Cache, up to 4.60 GHz)
i7-8700T 8th Gen Intel® Core™ i7-8700T Processor (12M Cache, up to 4.00 GHz)
i5-8500 8th Gen Intel® Core™ i5-8500 Processor (9M Cache, up to 4.10 GHz)
i5-8500T 8th Gen Intel® Core™ i5-8500T Processor (9M Cache, up to 3.50 GHz)
i3-8100 8th Gen Intel® Core™ i3-8100 Processor (6M Cache, 3.60 GHz)
i3-8100T 8th Gen Intel® Core™ i3-8100T Processor (6M Cache, 3.10 GHz)
DDR4 32G Certified DDR4 32GB 2666MHz RAM
DDR4 16G Certified DDR4 16GB 2666/2400/2133 MHz RAM
DDR4 8G Certified DDR4 8GB 2666/2400/2133 MHz RAM
DDR4 4G Certified DDR4 4GB 2666/2400/2133 MHz RAM
PWA-160W-WT 160W, 24V, 85V AC to 264V AC Power Adapter with 3-pin Terminal Block, Wide Temperature -30°C to +70°C
PWA-135W-WT-12V 135W, 12V, 85V AC to 264V AC Power Adapter with 3-pin Terminal Block, Wide Temperature -30°C to +70°C
PWA-120W1 120W, 24V, 90V AC to 264V AC Power Adapter with 3-pin Terminal Block
PWA-100W-12V 100W, 12V, 85V AC to 264V AC Power Adapter with 3-pin Terminal Block
SPC-5600 Fan Bracket Fan Bracket for SPC-5600
VESA Mount VESA Mounting Kit
DIN-RAIL Kit DIN Rail and VESA Mounting Kit
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth WiFi & Bluetooth Module with Antenna
