System |
|
Processor |
Quad Core 5th Generation Intel® Core™ i7-5850EQ/ i7-5700EQ (Broadwell-H)
|
|
Chipset |
Intel® QM87 |
|
BIOS |
AMI |
|
SIO |
IT8786E |
|
Memory |
2 DDR3L 1600MHz SO-DIMM, up to 32GB |
|
I/O Interface |
|
Serial |
4 COM RS-232/ 422/ 485 |
|
USB |
- 4 USB 3.0
- 3 USB 2.0 (2 External, 1 Internal) |
|
Isolated DIO |
16 Isolated DIO : 8 DI, 8 DO |
|
GPIO |
16 GPIO (Internal) |
|
LED |
Power, HDD, PoE |
|
SIM Card |
2 SIM Card Socket (External) |
|
Expansion |
|
Mini PCIe |
3 Mini PCIe Socket :
- 2 Full-size for PCIe/ USB/ External SIM Card/ mSATA
- 1 Half-size for PCIe/ USB
|
|
SUMIT A, B |
2 SUMIT Slot (Optional) |
|
Graphics |
|
Graphics Processor |
- Intel® Iris™ Pro Graphics 6200 (5850EQ)
- Intel® HD Graphics 5600 (5700EQ)
|
|
Interface |
- VGA : Up to 1920 x 1200 @ 60Hz
- DVI-D : Up to 1920 x 1080 @ 60Hz
- DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
- DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
- eDP : Up to 4096 x 2304 @ 60Hz
|
|
Storage |
|
SATA |
2 SATA III (6Gbps) |
|
mSATA |
2 SATA III (Mini PCIe Type, 6Gbps) |
|
SATA DOM |
1 SATA II (3Gbps) |
|
Storage Device |
- 1 CFast Socket, Push-in/ Push-out Ejector
- 2 Front-access 2.5" SSD/ HDD Tray
|
|
Audio |
|
Audio Codec |
Realtek ALC888S, 7.1 Channel HD Audio |
|
Audio Interface |
1 Mic-in, 1 Line-out |
|
Ethernet |
|
LAN 1 |
Intel® I218 Gigabit LAN supports iAMT 9.5 |
|
LAN 2 |
Intel® I210 Gigabit LAN |
|
PoE |
|
LAN 3 |
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 |
|
LAN 4 |
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 |
|
LAN 5 |
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 |
|
LAN 6 |
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210 |
|
Power |
|
Power Input |
6V to 36V, DC-in |
|
Power Interface |
- 3-pin Terminal Block : V+, V-, Frame Ground
- Mini-DIN 4-pin
|
|
Ignition Control |
16 Mode (Internal) |
|
Remote Switch |
3-pin Terminal Block : On, Off, IGN |
|
Surge Protection |
Up to 80V/1ms Transient Power |
|
Others |
|
TPM |
Optional Infineon SLB9665 supports TPM 2.0, LPC Interface |
|
Watchdog Timer |
Reset : 1 to 255 sec./min. per step |
|
Smart Management |
Wake on LAN, PXE supported |
|
HW Monitor |
Monitoring temperature, voltages. Auto throttling control when CPU overheats |
|
Software Support |
|
OS |
Windows 10, Windows 8, Windows 7, Linux |
|
Mechanical |
|
Dimension (W x L x H) |
260mm x 175mm x 79mm (10.2” x 6.9” x 3.1”) |
|
Weight |
2.8 kg (6.2 lb) |
|
Mounting |
- Wallmount by mounting bracket
- 2U Rackmount (Optional)
|
|
Environment |
|
Operating Temperature |
-25°C to 70°C (-13°F to 158°F) |
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Humidity |
5% to 95% Humidity, non-condensing |
|
Relative Humidity |
95% at 70°C |
|
Shock |
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
|
|
Vibration |
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
|
|
EMC |
CE, FCC, EN 50155, EN 50121-3-2 |
