System |
|
Processor |
Intel Atom® x6000E Processor (Elkhart Lake) |
|
BIOS |
AMI |
|
Memory |
2 DDR4 3200MHz SO-DIMM, up to 32GB |
|
OS |
Windows 10, Linux |
|
Graphics |
|
Graphics
Processor
|
Intel® UHD Graphics for 10th Gen Intel® Processors |
|
Interface |
Multiple independent display :
・VGA : 1920 x1200 @60Hz (Optional)
・LVDS : 1920 1200 @60Hz
・2 DDI : 4096 x2160 @60Hz
|
|
Ethernet |
|
LAN |
Intel® I225IT 2.5GigE LAN |
|
Audio |
|
Audio Codec |
On VCOM-BASE (Realtek ALC88S-VD standard support) |
|
Audio Interface |
HAD Bus |
|
I/O Interface |
|
Internal I/O |
・2 DDR4 SO-DIMM Socket
・1 FAN Connector
・RAW AB/CD Connector
|
|
Storage |
|
SATA |
2 SATA III (6Gbps) (to RAW A/B) |
|
Power |
|
Power Input |
ATX: 12V±5% / 5Vsb ±5%; or AT: 12V±5% |
|
Expansion |
|
PCIe |
・4 PCIe x1 (Configurable to 4 x1, 2 x2, 1 x4, 2 x1+1 x2, 1 x2+2 x1, to RAW A/B)
・1 PCIe x1 (to RAW A/B)
|
|
Others |
|
HW Monitor |
Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
|
TPM |
Infineon SLB9670 supports TPM 2.0, SPI Interface (Optional) |
|
Mechanical |
|
Dimensions(L x W) |
Compact size: 95mm x 95mm (3.74"x 3.74") |
|
Form Factor |
PICMG COM.0 Rev 3.0 Type 6 |
|
Environment |
|
Operating
Temperature
|
-40°C to 85°C with Fan sink |
|
Storage
Temperature
|
-40°C to 85°C |
|
Humidity |
5% to 95% Humidity, Non-condensing |
|
Relative Humidity |
95% @85°C |
|
EMC |
CE, FCC |
