System |
|
Processor |
MediaTek Genio 350 Processor with Quad-core Cortex-A53 @2.0GHz |
|
Memory |
2GB LPDDR4 SDRAM |
|
eMMC |
16GB eMMC |
|
OS |
・Android 10
・Linux Yocto 3.1
|
|
I/O Interface |
|
External I/O |
・1 IPEX Connector
・1 Debug Console Port
|
|
Internal I/O |
2 M.2 Golden Finger |
|
Graphics |
|
Graphics
Processor
|
・ARM Mali-G52 high-performance GPU
・3D graphics accelerator processing 1600M pixel/sec @800MHz
・Graphics engine supporting OpenGL® ES 3.2, OpenCL ES 2.0, and Vulkan 1.1 hardware acceleration
|
|
Video |
・Encode/Decode : Supports H.265 and H.264 video
decoding up to 1080p@60fps
・Vision DSP : Supports Cadence Tensilica Vision P6 and HiFi4
|
|
Display |
・Digital Display : up to 1920 x 1080
・4-lane MIPI DSI : up to 1920 x 1080
|
|
Camera |
・Dual 4-lane MIPI CSI-2
・Integrated image signal processor supports 13MP
|
|
Audio |
|
Audio Codec |
MediaTek MT6390/6357 |
|
Audio Interface |
2 Mic-in, 1 Headphone-out |
|
Expansion |
|
USB |
・1 USB 2.0 Host
・1 USB 2.0 OTG
|
|
UART |
2 UART (2-wire) |
|
SPI |
1 SPI |
|
I2C |
5 I2C |
|
GPIO |
14 GPIO |
|
MSDC |
1 MSDC |
|
ADC |
1 ADC |
|
PWM |
2 PWM |
|
Battery Gauge |
1 Battery Gauge |
|
Wireless |
|
Wi-Fi & BT |
・MediaTek MT6631
・Dual band (2.4GHz & 5GHz ) single stream Wi-Fi 802.11 a/b/g/n/ac RF
・Bluetooth 5.0
|
|
Power |
|
Power Input |
4.2V DC-in |
|
Mechanical |
|
Dimensions(W x L) |
60 mm x 45 mm (2.36" x 1.77") |
|
Environment |
|
Operating
Temperature
|
-40°C to 85°C |
|
Storage
Temperature
|
-40°C to 85°C |
|
Humidity |
5% to 95% Humidity, Non-condensing |
|
Relative
Humidity
|
95% at 85°C |
|
EMC |
CE, FCC |
